OpenRoads Geometry

Geometry – This volume will eventually become a Site / Subdivision design book, but in its first iteration, it only covers geometry layout of the boundary, interior road centerlines, Right-of-Way, and lot layout. This is all two-dimensional layout, and is intended on bringing focus to more of the OpenRoads geometry tool palette. Some of the activity and tools covered are Civil AccuDraw, importing ALGs, working with InRoads legacy ICS files, COGO Points, Alignments by COGO Points, Transform Geometry, the Geometry Builder, creating simple Annotation, and numerous other Geometry layout tools that a Mapping or Right-of-Way group would use. Hands-on exercises with sample files are included.
